316 Stainless Steel Square Tube

316 stainless steel square tube combines the legendary chloride resistance of grade 316 with geometric precision, making it ideal for structural, architectural, and marine applications. Enhanced with 2–3% molybdenum and a low carbon content (≤0.08%), this austenitic alloy resists pitting, crevice corrosion, and biofouling while maintaining a polished, weld-ready finish. Compliant with ASTM A554 and EN 10296-2. it outperforms 304 in coastal zones, chemical plants, and high-humidity interiors with a 50-year lifespan under proper maintenance.

Global Standards & Specifications

Region	Standard	Grade	Surface Finish
USA	ASTM A554	UNS S31600	Mirror (#8), Brushed (No. 4)
Europe	EN 10296-2	1.4401	Electropolished (Ra ≤0.3 µm)
Asia-Pacific	JIS G3466	SUS316 SQS	Pickled, Mill Finish

Key Advantages

Corrosion Resistance

PREN 28–32: Withstands coastal salt spray, chlorinated pools, and acidic vapors (pH ≥2.5).

Immune to stress corrosion cracking (SCC) in marine atmospheres (ASTM G36 compliant).

Structural Integrity

Cold-worked variants achieve 1.100 MPa tensile strength-ideal for load-bearing frameworks.

Seamless corners eliminate weak points, ensuring uniform stress distribution.

Aesthetic Versatility

Available in laser-cut, deburred edges for architectural cladding, handrails, and art installations.

Hygienic Design

Electropolished interiors (Ra ≤0.2 µm) prevent bacterial adhesion in food processing and labs.

Technical Specifications

Chemical Composition (wt%)

Cr	Ni	Mo	C	Mn	Si	P	S
16–18%	10–14%	2–3%	≤0.08%	≤2.0%	≤0.75%	≤0.045%	≤0.03%

Mechanical Properties

Wall Thickness	Yield Strength	Hardness (HV)	Max Operating Temp
1.0–6.0 mm	205–310 MPa	155–220	870°C (oxidizing)
6.1–12.0 mm	310–550 MPa	220–260	540°C (reducing)

Applications

Marine Engineering

Offshore platform walkways, ship railings, and desalination plant supports.

Architecture

UV-resistant curtain wall frames, corrosion-free balcony structures, and museum display systems.

Industrial

Chemical reactor scaffolding, cleanroom ventilation ducts, and pharmaceutical conveyor frames.

Consumer Goods

Luxury furniture, marine-grade outdoor grills, and modular shelving units.

Fabrication Guidelines

Cutting & Welding

Use laser/plasma cutting for burr-free edges; TIG weld with ER316L filler (argon shielding).

Surface Treatment

Passivate with nitric acid (20–50% v/v) post-fabrication to restore corrosion resistance.

Load Calculations

Allowable axial load: 12.5 kN/m for 50x50x3 mm tubes (safety factor = 1.5).

FAQs

Q1: How does 316 square tube differ from 304 in coastal applications?

A1: 316's molybdenum content resists pitting from chloride ions (e.g., seawater), whereas 304 may corrode within 2–5 years.

Q2: What surface finish minimizes maintenance?

A2: Electropolished (Ra ≤0.3 µm) or PVD-coated finishes reduce dirt accumulation and simplify cleaning.

Q3: Can it be welded to carbon steel frameworks?

A3: Yes-use 309L filler metal and isolate joints with dielectric coatings to prevent galvanic corrosion.

Q4: Maximum unsupported span for structural use?

A4: 3.2 meters for 50x50x4 mm tubes under 500 kg/m² distributed load (EN 1993-1-1 compliant).

Q5: Is it suitable for high-temperature exhaust systems?

A5: Limited to 540°C continuous use. For higher temps, consider 310S (up to 1.100°C).
